Rich smelly and farty - part 2 saga continues

themixer · Post by **themixer** » Sun Sep 15, 2013 8:05 pm

Car - 1991 Beretta 5 speed swapped
WOT Tech chip to run 3100 injectors

Purchased new injectors had one stick open and returned them. Contacted WOT tech to burn a chip to run a set of flow matched 3100 injectors.

Installed chip in car and the injectors turned it on and was presented with a lumpy idle. I get a check engine light plugged in my tech one and got 2 codes.

Mind you I have never had a code in this car that ever made any sense before.

45 - Rich Exhaust
43 - ESC Failure

What do I possibly have to change based off these codes? From what I am reading on the internet it could be ICM, looking at a chevy truck forum. I was unaware that there even was a light that would come on based off that.

RobertISaar · Post by **RobertISaar** » Sun Sep 15, 2013 10:00 pm

43 is the knock sensor. with it set, the PCM removes a set amount of timing in all conditions, which will cause drivability issues, including a crap idle. it could even be the cause of your DTC45.

since you have a tech1, this will certainly be helpful.

http://imgur.com/i15Zxi9,CzWz94S

Post by **3X00-Modified** » Mon Sep 16, 2013 7:42 am

Put your other chip back in... 3.1 and 3100 injectors are so close to the same it should run fine with the OEM chip... See if that corrects the issue.

themixer · Post by **themixer** » Mon Sep 16, 2013 8:21 am

The car did run with the stock chip, but continues to have a lumpy idle however no check engine light.

Has anyone else has similar issues to this? I am going to run though the testing of this knock sensor ASAP

themixer · Post by **themixer** » Sun Sep 22, 2013 1:19 pm

Knock sensor tested within spec

Circuit wire coming from ECU gives a constant 5 V nothing in the way of wiggling changes

From what the manual is saying I need to replace The ECU which has been done

With the knock sensor disconnected I've noticed that the car runs really really poorly. Is it possible that my knock sensor is sending some sort of signal to the computer causing it to run poorly?

Post by **3X00-Modified** » Mon Sep 23, 2013 8:58 am

knock sensor should not affect running with it disconnected, I've run my 3400 like that a fair share of times due to timing chain issues...

themixer · Post by **themixer** » Mon Sep 23, 2013 9:20 am

Well this is interesting news I must still have some sort of injector problem with this set

I wish we has a place in my area that could test them

Post by **3X00-Modified** » Mon Sep 23, 2013 9:28 am

Pull the rail and just turn the key on to prime the pump, see if they just spray fuel... They could be stuck open.

I have personally put 3100 injectors into a 3.1 to replace a bad 3.1 injector and the vehicle started and ran with them on the stock chip with no issues.

RobertISaar · Post by **RobertISaar** » Mon Sep 23, 2013 9:40 am

16.7 vs 17.5ish lb/hr.

it's about a 5% difference, so while not optimal, i'm sure there are people running injectors that have skewed over time to worse than that.

themixer · Post by **themixer** » Mon Oct 28, 2013 2:13 pm

I think I have figured out the best solution, 3400 swap

Sent from my iPad using Tapatalk

Post by **3X00-Modified** » Tue Oct 29, 2013 9:02 am

That wont fix an electrical issues..

themixer · Post by **themixer** » Tue Oct 29, 2013 9:13 am

I have doubts after testing all the wiring back to the ECU that there is an electrical issue, but if there is the entire car is being burned and sent to the junkyard.

themixer · Post by **themixer** » Thu Jan 02, 2014 10:40 am

Well an update on this, whatever injector stuck/broke seems fine now

it must have known, but in more exciting news

Koots · Post by **Koots** » Thu Jan 02, 2014 4:36 pm

3X00 donor van?

Nicey nice nice

themixer · Post by **themixer** » Thu Jan 02, 2014 4:37 pm

Yes yes yes
